Niko dimmer switch for Hue system
With this wireless and battery-free dimmer switch, you can effortlessly operate Philips Hue lamps. Determine in the Philips Hue app what each button must do (switching on and off, dimming, activating scene settings). No wall breaking or cable installation is needed. The dimmer switch can be mounted on a European flush-mounting box, screwed onto a wall (screws not included) or glued to a flat surface with double-sided adhesive strips (included). Please note that Philips Hue Bridge v2 is required and not included.
Product details
-
This product consists of several components. Below you will find an overview of all the component parts.
Technical datasheetsTechnical manualsEU declaration of conformityNiko dimmer switch for Hue system
Reference code360-51001With this wireless and battery-free dimmer switch, you can effortlessly operate Philips Hue lamps. Determine in the Philips Hue app what each button must do (switching on and off, dimming, activating scene settings). No wall breaking or cable installation is needed. The dimmer switch can be mounted in a European flush-mounting box, screwed onto a wall (screws not included) or glued to a flat surface with double-sided adhesive strips (included). The central plate and faceplate must be ordered separately. The dimmer switch combines with any Niko Pure, Niko Intense and Niko Original faceplate in the colour of your choice. Philips Hue Bridge v2 not required and not included.
Specification description
Niko dimmer switch for Hue system.
- Power supply: integrated kinetic energy Harvester
- Modulation: Shift Keying (OQPSK)
- Maximum RF power: 7 dBm / 5 mW
- Data rate: 250 kbps
- Configuration: Philips Hue app
- Mounting height: 110 cm
- Maximum range (indoor): up to 20 m
- Antenna: integrated antenna
- Marked: CE
- Number of control buttons: 4 control buttons
- Communication protocol: Zigbee® Green Power
- Operating frequency: 2.4 GHz
- Protection degree: IP20
- Fixing method
screw fixing or gluing
- Ambient temperature: -25 – +65 °C
- Dimensions (HxWxD): 83 x 83 x 15 mm
- Weight: 25 g
- Marking: CE
Base for a wireless dimmer switch, 60 x 71 mm, claw fixing
Reference code360-00000Base with claw fixing for mounting a wireless dimmer switch (for Hue system, EnOcean®, Bluetooth® and KNX®). You can click it together and combine it with one or more flush-mounting mechanisms from Niko.
This article is protected by at least one patent (application). For more info on patents, see www.niko.eu/innovation.
Base for a wireless dimmer switch, 60 x 71 mm, screw fixing
Reference code360-00001Base with screw fixing for mounting a wireless dimmer switch (for Hue system, EnOcean®, Bluetooth® and KNX®). You can click it together and combine it with one or more flush-mounting mechanisms from Niko.
This article is protected by at least one patent (application). For more info on patents, see www.niko.eu/innovation.
Base for a wireless dimmer switch, 71 x 71 mm, claw fixing
Reference code360-00002Base with claw fixing for mounting a wireless dimmer switch (for Hue system, EnOcean®, Bluetooth® and KNX®). You can click it together and combine it with one or more flush-mounting mechanisms from Niko.
This article is protected by at least one patent (application). For more info on patents, see www.niko.eu/innovation.
Base for a wireless dimmer switch, 71 x 71 mm, screw fixing
Reference code360-00003Base with screw fixing for mounting a wireless dimmer switch (for Hue system, EnOcean®, Bluetooth® and KNX®). You can click it together and combine it with one or more flush-mounting mechanisms from Niko.
This article is protected by at least one patent (application). For more info on patents, see www.niko.eu/innovation.
Double key, for wireless dimmer switch (Hue®, Bluetooth®, EnOcean®, KNX®), cream
Reference code100-00060This double key with two control buttons can be used for the wireless Niko dimmer switch for Hue system, EnOcean®, Bluetooth® and KNX®.
Conveniently control various lighting points.
-
Niko has already created this product for you. We have combined several articles into one finished product, which is available in different variations.
Niko dimmer switch for Hue system, Niko Original cream
Reference code100-91004With this wireless and battery-free dimmer switch, you can operate the Philips Hue lamps effortlessly. Determine in the Philips Hue app what each button must do (switching on and off, dimming, activating scene settings). Mechanism including push button and faceplate cream. Philips Hue Bridge v2 required and not included.
-
