Finishing set for 2 single coax connections for TV and FM and a satellite connection

Reference code
Technical datasheets
Certificaten CE-Marking


Central plate consists of 2 single coax connections and a satellite connection on top. Finishing colour: black coated.

Specification description

Finishing set for 2 single coax connections for TV and FM and a satellite connection.

  • Function: The central plate is clicked onto a TV/FM outlet with a single coax connection.
  • Material central plate: The central plate is enamelled and made of rigid PC and ASA.
  • Colour: black coated (approximately NCS S 9000 N, RAL 9004)
  • Print: The central plate is engraved with 'TV’ and 'FM'.
  • Dismantling: To dismount simply pull the central plate off the mechanism.
  • Protection degree: IP41 for the combination of a mechanism, central plate and faceplate
  • Impact resistance: The combination of a mechanism, a central plate and a faceplate has an impact-resistance of IK06
  • Fire safety
    • The plastic parts of the central plate are self-extinguishing (comply with a filament test of 650°C)
    • The plastic parts of the central plate are halogen-free.
  • Dimensions of finishing: 45 x 45 mm (HxW)
  • Dimensions (HxWxD): 44.5 x 44.5 x 8.6 mm
  • Marking: CE
Alternative colors
  • 100-69551
    Colour cream
    Reference code 100-69551
  • 101-69551
    Colour white
    Reference code 101-69551
  • 102-69551
    Colour light grey
    Reference code 102-69551
  • 121-69551
    Colour sterling
    Reference code 121-69551
  • 122-69551
    Colour anthracite
    Reference code 122-69551
  • 123-69551
    Colour bronze
    Reference code 123-69551
  • 124-69551
    Colour dark brown
    Reference code 124-69551
  • 154-69551
    Colour white coated
    Reference code 154-69551
  • 157-69551
    Colour champagne coated
    Reference code 157-69551
  • 161-69551
    Colour black coated
    Reference code 161-69551
  • 200-69551
    Colour piano black coated
    Reference code 200-69551
  • 220-69551
    Colour steel grey coated
    Reference code 220-69551
  • 221-69551
    Colour gold coated
    Reference code 221-69551
