Presence detector, 230 V, 8 m, for flush-mounting box, white

Reference code
350-20056
Technical datasheets
Technical manuals
Certificaten CE-Marking

Description

This 1-channel presence and absence detector is suitable for flush-mounting in the ceiling and is used for switching indoor lighting. This presence detector has a circular detection range of up to 12 m in diameter. The device has a built-in light sensor and switches the lighting on and off automatically. Manual operation is also possible using the N.O. push button (to be ordered separately). After the pre-set time delay, the light is switched off automatically. The device has an IP20 protection degree and conforms to the European directive, EN 60669-2-1, for EMC and safety.

Finishing colour: white

Specification description

Presence detector, 230 V, 8 m, for flush-mounting box, white.

  • Detector technology: PIR
  • Input voltage: 230 Vac ± 10 %, 50 Hz
  • Detector output: 230 V (ON/OFF)
  • Maximum MCB rating: 10 A (limited by national installation rules)
  • Number of channels: 1 channel
  • Light intensity range: 30 lux – 2000 lux
  • Switch-off delay: 5 s – 30 min
  • Detection angle: 360°
  • Detection range (PIR): ø 8 m from a height of 3 m
  • Ambient temperature: -5 – +50 °C
  • Mounting method: flush-mounting box
  • Mounting height: 2.5 – 4 m
  • Usage: for indoor use only
  • Relay contact: N.O. (max. 10 A)
  • Maximum load incandescent and halogen lamps (cosφ = 1): 2300 W
  • Maximum load fluorescent lamps (cosφ ≥ 0.5): 1200 VA
  • Maximum load low voltage halogen lamps: 1200 W
  • Maximum load economy lamps (CFLi): 350 W
  • Maximum load LED lamps 230 V: 350 W
  • Maximum capacitive load: 140 µF
  • Maximum switching current: 165 A/20 ms – 800 A/200 µs
  • Dimensions (HxWxD): 90 x 90 x 56 mm
  • Dimensions visible (HxWxD): 90 x 90 x 24 mm
  • Protection degree: IP20
  • Protection class: Class II device
  • Marking: CE
