Finishing set for single coaxial connection and network connection RJ45, light grey

Reference code
102-65702
Technical datasheets
Certificaten CE-Marking

Description

Central plate Niko Pure White coated for single coaxial connection and network connection. The first input is intended for an EDU TV connection. The second is intended for a network connection. Finishing colour: light grey

Specification description

Finishing set for single coaxial connection and network connection RJ45, light grey.

  • Material central plate: The central plate is made of rigid PC and ASA. The base material is coloured in mass.
  • Colour: light grey (coloured in mass, approximately NCS S 1002 - Y, RAL 080 80 05)
  • Dismantling: To dismount simply pull the central plate off the mechanism.
  • Protection degree: IP41 for the combination of a mechanism, central plate and faceplate
  • Impact resistance: The combination of a mechanism, a central plate and a faceplate has an impact-resistance of IK06
  • Fire safety
    • the plastic parts of the central plate are self-extinguishing (comply with a filament test of 650 °C)
    • the plastic parts of the central plate are halogen-free
  • Dimensions of finishing: 45 x 45 mm (HxW)
  • Dimensions (HxWxD): 44.5 x 44.7 x 8.6 mm
  • Marking: CE
Alternative colors
  • 100-65702
    Colour cream
    Reference code 100-65702
  • 101-65702
    Colour white
    Reference code 101-65702
  • 102-65702
    Colour light grey
    Reference code 102-65702
  • 121-65702
    Colour sterling coated
    Reference code 121-65702
  • 122-65702
    Colour anthracite coated
    Reference code 122-65702
  • 123-65702
    Colour bronze coated
    Reference code 123-65702
  • 124-65702
    Colour dark brown coated
    Reference code 124-65702
  • 154-65702
    Colour white coated
    Reference code 154-65702
  • 157-65702
    Colour champagne coated
    Reference code 157-65702
  • 161-65702
    Colour black coated
    Reference code 161-65702
  • 200-65702
    Colour piano black coated
    Reference code 200-65702
  • 220-65702
    Colour blue grey coated
    Reference code 220-65702
  • 221-65702
    Colour gold coated
    Reference code 221-65702
